Product content
Ceramic lining composite Y type is used for power plant coal powder, ash slag, mine powder, tailings, backfill, coal from coal mines, concentrators, coking plant coke particles, and sintering plant materials. The service life is 15 times longer than ordinary steel pipes. Above, it can also be used for the transportation of molten aluminum and corrosive media. The thermite-centrifugal method prepares the ceramic-lined steel pipe using the high temperature generated by the reaction itself to melt the reaction products and separate them under the action of centrifugal force to form a steel pipe lined with alumina ceramics, with low energy consumption and fewer processes.
Product parameters
Physical and mechanical properties of ceramic steel pipes
|
Data project |
hardnessHVKgf/mm2 |
Crush strength ① MPa |
proportiong /cm3 |
Shear strength②MPa |
Absolutely rough mm |
Linear expansion coefficient③×10-6K-1 |
|
Ceramic steel pipe |
1100-1400 |
350-400 |
4.6-4.7 With transition layer |
15 |
Dn≤150为0.35 Dn>150为0.12 |
8.5-9 |
|
20#Carbon Steel Pipe |
149 |
411 |
7.85 |
Hfgh |
New 0.05-0.1 Old 0.4-0.6 |
14-15 |
Note: ①The thickness of the seamless steel pipe is 8mm, the total thickness of the ceramic layer and the transition layer is 2.5～3.5mm, the strength when the MPa ceramic inside the tube is crushed from the outside of the tube.
②The strength when the ceramic layer is pressed out of the seamless steel pipe in the axial direction of the ceramic steel pipe.
③The temperature range is -30～500℃.
FAQ
1. What is your mode of transportation?
Answer: Shipping, shipping
2. Why is your price higher than others?
Answer: Because the quality of the products must be guaranteed, the raw materials we use are all of high quality and strictly controlled. We cannot achieve the lowest price, but we will ensure that the quality is passed. So there will be differences in prices. The quality of raw materials differs greatly in price.
3. Can it be made in strict accordance with the caliber, specification and length provided by me?
Answer: General conventional products are implemented according to standard specifications, and non-conventional products can be customized.
4. I have a large demand, can I offer a discount?
Answer: Yes, depending on your specific needs, large quantities can be discounted.
