Two-stage adjustable overflow pipe
Ep1≤0.03,Ep2≤0.05
Sorting efficiency ≥95%
Main technical parameters
|
Specification and model |
Barrel diameter (mm) |
Feed particle size |
Feed pressure |
Processing capacity |
Medium circulation volume |
|
|
A section of |
Section 2 |
(mm) |
(MPa) |
(t/h) |
(m³/h) |
|
|
WTMC600/400 |
600 |
400 |
≤30 |
0.06~0.10 |
40~60 |
250~350 |
|
WTMC710/500 |
710 |
500 |
≤35 |
0.08~0.12 |
60~100 |
350~450 |
|
WTMC850/600 |
850 |
600 |
≤45 |
0.10~0.14 |
100~160 |
500~650 |
|
WTMC900/650 |
900 |
650 |
≤50 |
0.12~0.16 |
120~180 |
600~800 |
|
WTMC1000/710 |
1000 |
710 |
≤55 |
0.15~0.18 |
160~220 |
800~1000 |
|
WTMC1100/780 |
1100 |
780 |
≤60 |
0.18~0.22 |
200~280 |
900~1200 |
|
WTMC1200/850 |
1200 |
850 |
≤70 |
0.20~0.28 |
260~350 |
1200~1400 |
|
WTMC1300/920 |
1300 |
920 |
≤80 |
0.24~0.30 |
320~400 |
1400~1800 |
|
WTMC1400/1000 |
1400 |
1000 |
≤90 |
0.28~0.36 |
400~500 |
1800~2200 |
